Varsity Series® Rollformed Louvre

Louvreclad Varsity Series® combines robust steel construction with integrated single and two-stage louvre options, delivering proven ventilation performance, clean aesthetics, and efficient airflow for mechanical screening applications.

Why choose Varsity Series®

Performance

Enhanced Airflow and Low Pressure Drops

AS 4740:2025 verified Class B rain resistance up to 1.5 m/s core velocity, achieving up to 99.2% rain penetration effectiveness, with Class 2–3 aerodynamic performance.

Aesthetics

Versatile Steel Design

Features roll-formed colour-coated steel with a 125mm pitch. Available in any Colorbond or Unicote finish, suitable for horizontal linear aesthetics in various applications.

Design

Precision Sheet Metal Construction

Fabricated with 0.55mm base metal thickness, offering high strength and durability. Available as prefabricated modular panels or continuous louvres.

Sustainability

Two-Stage Integration

Combines with Venus Series® chevron louvre profile for enhanced rain defence without compromising airflow, making it a standout choice for applications requiring both high performance and weatherproofing.

Explore Varsity Series® profile options

Varsity Series®

Single stage roll-formed steel louvres

download Revit file request DWG file

Class 2

Aerodynamics

0.56 CD

Discharge Coefficient

0.211 m2

Effective Aerodynamic Area

53 %

Free Open Area

94 mm

Depth

125 mm

Pitch

1500 mm

Max span

18kg/m2

Weight

Horizontal, Vertical

Orientation

Varsity Series® Two Stage

Two-stage roll-formed steel louvres

request DWG file

Class 3

Aerodynamics

0.35 CD

Discharge Coefficient

0.091 m2

Effective Aerodynamic Area

42 %
